Search results for pfb
Search results for pfb

Search results for: 'pfb/'

Results:

Remaining

Search Entry:

Fan Type

Voltage Rated

Size / Dimension

Width

Air Flow

Static Pressure

Noise

RPM

Power (Watts)

Bearing Type

Features

Ingress Protection

View as Grid List

Show

per page

Part Number	Size/Dimension	Width	Bearing	Voltage	Air Flow	Static Pressure	Noise	Power	RPM	Termination
PFB0924EHE-F00	Square-92mm L X 92mm H	38.00mm	Ball	24 VDC	103.67 CFM (2.936 m3/min)	0.691 inchH2O (17.56 mmH2O)	54.0 dB(A)	7.92 W	4800 RPM	2 wire leads
PFB0924EHE	Square-92mm L X 92mm H	38.00mm	Ball	24 VDC	103.67 CFM (2.936 m3/min)	0.691 inchH2O (17.56 mmH2O)	54.0 dB(A)	7.92 W	4800 RPM	2 wire leads
PFB0924DHE-T500	Square-92mm L X 92mm H	38.00mm	Ball	24 VDC	175.03 CFM (4.957 m3/min)	1.819 inchH2O (46.21 mmH2O)	66.5 dB(A)	34.80 W	8000 RPM	2 wire leads
PFB0924DHE-R00	Square-92mm L X 92mm H	38.00mm	Ball	24 VDC	175.03 CFM (4.957 m3/min)	1.819 inchH2O (46.21 mmH2O)	66.5 dB(A)	34.80 W	8000 RPM	3 wire leads
PFB0924DHE-F00	Square-92mm L X 92mm H	38.00mm	Ball	24 VDC	175.03 CFM (4.957 m3/min)	1.819 inchH2O (46.21 mmH2O)	66.5 dB(A)	34.80 W	8000 RPM	3 wire leads
PFB0924DHE	Square-92mm L X 92mm H	38.00mm	Ball	24 VDC	175.03 CFM (4.957 m3/min)	1.819 inchH2O (46.21 mmH2O)	66.5 dB(A)	34.80 W	8000 RPM	2 wire leads
PFB0912UHE-T500	Square-92mm L X 92mm H	38.00mm	Ball	12 VDC	153.52CFM (4.347 m3/min)	1.449 inchH2O (36.79 mmH2O)	64.0 dB(A)	23.52 W	7000 RPM	2 wire leads
PFB0912UHE	Square-92mm L X 92mm H	38.00mm	Ball	12 VDC	153.52CFM (4.347 m3/min)	1.449 inchH2O (36.79 mmH2O)	64.0 dB(A)	23.52 W	7000 RPM	2 wire leads
PFB0912EHE-T500	Square-92mm L X 92mm H	38.00mm	Ball	12 VDC	103.67 CFM (2.936 m3/min)	0.691 inchH2O (17.56 mmH2O)	54.0 dB(A)	8.16 W	4800 RPM	2 wire leads
PFB0912DHE-F00	Square-92mm L X 92mm H	38.00mm	Ball	12 VDC	175.03 CFM (4.957 m3/min)	1.819 inchH2O (46.21 mmH2O)	66.5 dB(A)	37.20 W	8000 RPM	3 wire leads
PFB0824UHE-T500	Square-80mm L X 80mm H	38.00mm	Ball	24 VDC	107.30 CFM (3.038 m3/min)	1.368 inchH2O (34.75 mmH2O)	61.0 dB(A)	18.48 W	7500 RPM	2 wire leads
PFB0824UHE-F00	Square-80mm L X 80mm H	38.00mm	Ball	24 VDC	107.30 CFM (3.038 m3/min)	1.368 inchH2O (34.75 mmH2O)	61.0 dB(A)	18.48 W	7500 RPM	2 wire leads
PFB0824UHE	Square-80mm L X 80mm H	38.00mm	Ball	24 VDC	107.30 CFM (3.038 m3/min)	1.368 inchH2O (34.75 mmH2O)	61.0 dB(A)	18.48 W	7500 RPM	2 wire leads
PFB0824EHE	Square-80mm L X 80mm H	38.00mm	Ball	24 VDC	79.23 CFM (2.243 m3/min)	0.767 inchH2O (19.50 mmH2O)	53.0 dB(A)	8.52 W	5600 RPM	2 wire leads
PFB0824DHEYDG	Square-80mm L X 80mm H	38.00mm	Ball	24 VDC	132.56 CFM (3.754 m3/min)	2.03 inchH2O (51.57 mmH2O)	65.0 dB(A)	32.40 W	9000 RPM	4 wire leads
PFB0824DHE-T50F	Square-80mm L X 80mm H	38.00mm	Ball	24 VDC	132.56 CFM (3.754 m3/min)	2.03 inchH2O (51.57 mmH2O)	65.0 dB(A)	32.40 W	9000 RPM	3 wire leads
PFB0824DHE-F00	Square-80mm L X 80mm H	38.00mm	Ball	24 VDC	132.56 CFM (3.754 m3/min)	2.03 inchH2O (51.57 mmH2O)	65.0 dB(A)	32.40 W	9000 RPM	3 wire leads
PFB0824DHE	Square-80mm L X 80mm H	38.00mm	Ball	24 VDC	132.56 CFM (3.754 m3/min)	2.03 inchH2O (51.57 mmH2O)	65.0 dB(A)	32.40 W	9000 RPM	2 wire leads
PFB0812UHE-F00	Square-80mm L X 80mm H	38.00mm	Ball	12 VDC	107.30 CFM (3.038 m3/min)	1.368 inchH2O (34.75 mmH2O)	61.0 dB(A)	18.60 W	7500 RPM	3 wire leads
PFB0812UHE-EP	Square-80mm L X 80mm H	38.00mm	Ball	12 VDC	91.87CFM (2.601 m3/min)	0.974 inchH2O (24.74 mmH2O)	57.5 dB(A)	11.88 W	6550 RPM	4 wire leads
PFB0812DHE-TYNT	Square-80mm L X 80mm H	38.00mm	Ball	12 VDC	132.60 CFM (3.754 m3/min)	2.03 inchH2O (51.57 mmH2O)	66.0 dB(A)	33.00 W	9000 RPM	4 wire leads
PFB0812DHE-T500	Square-80mm L X 80mm H	38.00mm	Ball	12 VDC	132.60 CFM (3.754 m3/min)	2.03 inchH2O (51.57 mmH2O)	65.0 dB(A)	33.00 W	9000 RPM	2 wire leads
PFB0812DHE-F00	Square-80mm L X 80mm H	38.00mm	Ball	12 VDC	132.60 CFM (3.754 m3/min)	2.03 inchH2O (51.57 mmH2O)	65.0 dB(A)	33.00 W	9000 RPM	3 wire leads
PFB1224GHE	Square-120mm L X 120mm H	38.00mm	Ball	24 VDC	217.79CFM (6.167 m3/min)	1.075 inchH2O (27.31 mmH2O)	64.0 dB(A)	32.40 W	4800 RPM	2 wire leads
PFB1224UHE-T50F	Square-120mm L X 120mm H	38.00mm	Ball	24 VDC	252.85CFM (7.160 m3/min)	1.412 inchH2O (35.877 mmH2O)	66.5 dB(A)	48.00 W	5500 RPM	3 wire leads
PFB1224UHE-R00	Square-120mm L X 120mm H	38.00mm	Ball	24 VDC	252.85CFM (7.160 m3/min)	1.412 inchH2O (35.877 mmH2O)	66.5 dB(A)	48.00 W	5500 RPM	3 wire leads
PFB1224UHE	Square-120mm L X 120mm H	38.00mm	Ball	24 VDC	252.85CFM (7.160 m3/min)	1.412 inchH2O (35.877 mmH2O)	66.5 dB(A)	48.00 W	5500 RPM	2 wire leads
PFB0812DHE	Square-80mm L X 80mm H	38.00mm	Ball	12 VDC	132.60 CFM (3.754 m3/min)	2.03 inchH2O (51.57 mmH2O)	65.0 dB(A)	33.00 W	9000 RPM	2 wire leads
PFB0624SHE-TZNY	Square-60mm L X 60mm H	38.00mm	Ball	24 VDC	43.57CFM (1.234 m3/min)	0.918 inchH2O (23.32 mmH2O)	50.5 dB(A)	6.72 W	8000 RPM	3 wire leads
PFB0624SHE	Square-60mm L X 60mm H	38.00mm	Ball	24 VDC	43.57CFM (1.234 m3/min)	0.918 inchH2O (23.32 mmH2O)	50.5 dB(A)	6.72 W	8000 RPM	2 wire leads
