Search results for afb
Search results for afb

Search results for: 'afb'

Results:

Remaining

Search Entry:

Fan Type

Voltage Rated

Size / Dimension

Width

Air Flow

Static Pressure

Noise

RPM

Power (Watts)

Bearing Type

Features

Ingress Protection

View as Grid List

Show

per page

Part Number	Size/Dimension	Width	Bearing	Voltage	Air Flow	Static Pressure	Noise	Power	RPM	Termination
AFB0612H-A	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	23.38CFM (0.662 m3/min)	0.211 inchH2O (5.35 mmH2O)	34.0 dB(A)	1.68 W	4250 RPM	2 lead wires
AFB0612H-AF00	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	23.38CFM (0.662 m3/min)	0.211 inchH2O (5.35 mmH2O)	34.0 dB(A)	1.68 W	4250 RPM	3 lead wires
AFB0612H-AR00	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	23.38CFM (0.662 m3/min)	0.211 inchH2O (5.35 mmH2O)	34.0 dB(A)	1.68 W	4250 RPM	3 lead wires
AFB0612HC-R00	Square-60mm L X 60mm H	13.00mm	Ball	12 VDC	21.22 CFM (0.601 m3/min)	0.163 inchH2O (4.15 mmH2O)	31.5 dB(A)	1.68 W	4200 RPM	3 lead wires
AFB0612HD	Square-60mm L X 60mm H	20.00mm	Ball	12 VDC	16.60CFM (0.470 m3/min)	0.189 inchH2O (04.80 mmH2O)	28.0 dB(A)	1.32 W	4000 RPM	2 lead wires
AFB0612H-EP	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	22.63CFM (0.662 m3/min)	0.211 inchH2O (5.35 mmH2O)	34.0 dB(A)	1.68 W	4250 RPM	2 lead wires
AFB0612HH-A	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	27.55CFM (0.780 m3/min)	0.297 inchH2O (7.55 mmH2O)	40.0 dB(A)	2.04 W	5000 RPM	2 lead wires
AFB0612HH-AF00	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	27.55CFM (0.780 m3/min)	0.297 inchH2O (7.55 mmH2O)	40.0 dB(A)	2.04 W	5000 RPM	3 lead wires
AFB0612HH-AR00	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	27.55CFM (0.780 m3/min)	0.297 inchH2O (7.55 mmH2O)	40.0 dB(A)	2.04 W	5000 RPM	3 lead wires
AFB0612HHD	Square-60mm L X 60mm H	20.00mm	Ball	12 VDC	18.36CFM (0.520 m3/min)	0.229 inchH2O (5.81 mmH2O)	31.0 dB(A)	1.80 W	4400 RPM	2 lead wires
AFB0612L-A	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	16.81CFM (0.476 m3/min)	0.113 inchH2O (2.86 mmH2O)	26.5 dB(A)	0.96 W	3100 RPM	2 lead wires
AFB0612L-AF00 (EOL)	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	16.81CFM (0.476 m3/min)	0.113 inchH2O (2.86 mmH2O)	26.5 dB(A)	0.96 W	3100 RPM	3 lead wires
AFB0612L-AR00 (EOL)	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	16.81CFM (0.476 m3/min)	0.113 inchH2O (2.86 mmH2O)	26.5 dB(A)	0.96 W	3100 RPM	3 lead wires
AFB0612LC	Square-60mm L X 60mm H	13.00mm	Ball	12 VDC	15.40 CFM (0.436 m3/min)	0.083 inchH2O (2.11 mmH2O)	24.0 dB(A)	0.96 W	3000 RPM	2 lead wires
AFB0612LC-F00	Square-60mm L X 60mm H	13.00mm	Ball	12 VDC	15.40 CFM (0.436 m3/min)	0.083 inchH2O (2.11 mmH2O)	24.0 dB(A)	0.96 W	3000 RPM	3 lead wires
AFB0612LC-R00	Square-60mm L X 60mm H	13.00mm	Ball	12 VDC	15.40 CFM (0.436 m3/min)	0.083 inchH2O (2.11 mmH2O)	24.0 dB(A)	0.96 W	3000 RPM	3 lead wires
AFB0612LD	Square-60mm L X 60mm H	20.00mm	Ball	12 VDC	13.06 CFM (0.370 m3/min)	0.119 inchH2O (3.03 mmH2O)	24.0 dB(A)	0.84 W	3200 RPM	2 lead wires
AFB0612M-A	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	19.78 CFM (0.560 m3/min)	0.155 inchH2O (3.93 mmH2O)	31.0 dB(A)	1.56 W	3600 RPM	2 lead wires
AFB0612M-AF00	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	19.78 CFM (0.560 m3/min)	0.155 inchH2O (3.93 mmH2O)	31.0 dB(A)	1.56 W	3600 RPM	3 lead wires
AFB0612M-AR00	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	19.78 CFM (0.560 m3/min)	0.155 inchH2O (3.93 mmH2O)	31.0 dB(A)	1.56 W	3600 RPM	3 lead wires
AFB0612MC	Square-60mm L X 60mm H	13.00mm	Ball	12 VDC	18.15 CFM (0.514 m3/min)	0.119 inchH2O (3.02 mmH2O)	28.0 dB(A)	1.32 W	3600 RPM	2 lead wires
AFB0612MC-F00	Square-60mm L X 60mm H	13.00mm	Ball	12 VDC	18.15 CFM (0.514 m3/min)	0.119 inchH2O (3.02 mmH2O)	28.0 dB(A)	1.32 W	3600 RPM	3 lead wires
AFB0612MC-R00	Square-60mm L X 60mm H	13.00mm	Ball	12 VDC	18.15 CFM (0.514 m3/min)	0.119 inchH2O (3.02 mmH2O)	28.0 dB(A)	1.32 W	3600 RPM	3 lead wires
AFB0612MD	Square-60mm L X 60mm H	20.00mm	Ball	12 VDC	14.83 CFM (0.420 m3/min)	0.151 inchH2O (3.83 mmH2O)	26.0 dB(A)	1.08 W	3600 RPM	2 lead wires
AFB0612SH-A	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	34.15CFM (0.967 m3/min)	0.422 inchH2O (10.73 mmH2O)	44.5 dB(A)	3.24 W	6000 RPM	2 lead wires
AFB0612SH-AB (EOL)	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	34.15CFM (0.967 m3/min)	0.422 inchH2O (10.73 mmH2O)	44.5 dB(A)	3.24 W	6000 RPM	2 lead wires
AFB0612SH-ABF00	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	34.15CFM (0.967 m3/min)	0.422 inchH2O (10.73 mmH2O)	44.5 dB(A)	3.24 W	6000 RPM	3 lead wires
AFB0612SH-AF00	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	34.15CFM (0.967 m3/min)	0.422 inchH2O (10.73 mmH2O)	44.5 dB(A)	3.24 W	6000 RPM	3 lead wires
AFB0612SH-AR00	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	34.15CFM (0.967 m3/min)	0.422 inchH2O (10.73 mmH2O)	44.5 dB(A)	3.24 W	6000 RPM	3 lead wires
AFB0612SH-TA50	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	34.15CFM (0.967 m3/min)	0.422 inchH2O (10.73 mmH2O)	44.5 dB(A)	3.24 W	6000 RPM	2 lead wires
