Parts		 Part Number Image Size/Dimension Width Bearing Voltage Air Flow Static Pressure Noise Power RPM Termination
BFB04505LA-C
BFB04505LA-C, 45x45x45mm, 0.40 W, 0.08A, ball, blower, speed 3900 RPM, dc fan, delta BFB04505LA-C, 45x45x45mm, 0.40 W, 0.08A, ball, blower, speed 3900 RPM, dc fan, delta
Square-45mm L X 45mm H 10.30mm Ball 5 VDC 1.99 CFM (0.057 m3/min) 0.212 inchH2O (5.38 mmH2O) 21.5 dB(A) 0.40 W 3900 RPM 2 lead wires
BFB04505LA-CF00
https://www.delta-fan.com/Download/Images/BFB45x45x10-C.jpg https://www.delta-fan.com/Download/Images/BFB45x45x10-C.jpg
Square-45mm L X 45mm H 10.30mm Ball 5 VDC 1.997 CFM (0.057m3/min) 0.212 inchH2O (5.38 mmH2O) 21.5 dB(A) 0.40 W 3900 RPM 3 lead wires
BFB04512HD
BFB04512HD BFB04512HD
Square-45mm L X 45mm H 20.00mm Ball 12 VDC 4.91 CFM (0.139 m3/min) 0.366 inchH2O (9.29 mmH2O) 24.5 dB(A) 1.20 W 3800 RPM 2 lead wires
BFB04512HD-R00
BFB04512HD-R00, 45x45x20 mm, 12 VDC, 0.10 A, 1.20 Watts, 3800 RPM, 3 lead wires, Locked Rotor Sensor, ball bearing, blower, dc fan, delta BFB04512HD-R00, 45x45x20 mm, 12 VDC, 0.10 A, 1.20 Watts, 3800 RPM, 3 lead wires, Locked Rotor Sensor, ball bearing, blower, dc fan, delta
Square-45mm L X 45mm H 20.00mm Ball 12 VDC 4.91 CFM (0.139 m3/min) 0.366 inchH2O (9.29 mmH2O) 24.5 dB(A) 1.20 W 3800 RPM 3 lead wires
BFB04512HHA-C
BFB04512HHA-C BFB04512HHA-C
Square-45mm L X 45mm H 10.30mm Ball 12 VDC 3.49 CFM (0.099 m3/min) 0.560 inchH2O (14.22 mmH2O) 35.5 dB(A) 1.56 W 5900 RPM 2 lead wires
BFB04512HHA-CF00
BFB04512HHA-CF00 BFB04512HHA-CF00
Square-45mm L X 45mm H 10.30mm Ball 12 VDC 3.49 CFM (0.099 m3/min) 0.560 inchH2O (14.22 mmH2O) 35.5 dB(A) 1.56 W 5900 RPM 3 lead wires
BFB04512HHA-CZ0T
https://www.delta-fan.com/Download/Images/BFB04512HHA-CZ0T.jpg https://www.delta-fan.com/Download/Images/BFB04512HHA-CZ0T.jpg
Square-45mm L X 45mm H 10.30mm Ball 12 VDC 3.60 CFM (0.102 m3/min) 0.598 inchH2O (15.20 mmH2O) 36.0 dB(A) 1.68 W 6100 RPM 4 lead wires
BFB04512MD
BFB04512MD BFB04512MD
Rounded/Rect-45mm L X45mm H 20.00mm Ball 12 VDC 4.24 CFM (0.120 m3/min) 0.269 inchH2O (6.83 mmH2O) 21.0 dB(A) 0.84 W 3300 RPM 2 lead wires
BFB04512MD-F00
BFB04512MD-F00 BFB04512MD-F00
Rounded/Rect-45mm L X45mm H 20.00mm Ball 12 VDC 4.24 CFM (0.120 m3/min) 0.269 inchH2O (6.83 mmH2O) 21.0 dB(A) 0.84 W 3300 RPM 3 lead wires
BFB04512MD-R00
BFB04512MD-R00 BFB04512MD-R00
Rounded/Rect-45mm L X45mm H 20.00mm Ball 12 VDC 4.24 CFM (0.120 m3/min) 0.269 inchH2O (6.83 mmH2O) 21.0 dB(A) 0.84 W 3300 RPM 3 lead wires
BFB04512VHD
BFB04512VHD, 45x45x20 mm, 12 VDC, 0.16 A, 1.92 Watts, 4500 RPM, 2 lead wires, ball bearing, blower, dc fan, delta BFB04512VHD, 45x45x20 mm, 12 VDC, 0.16 A, 1.92 Watts, 4500 RPM, 2 lead wires, ball bearing, blower, dc fan, delta
Rounded/Rect-45mm L X45mm H 20.00mm Ball 12 VDC 6.01 CFM (0.170 m3/min) 0.557 inchH2O (14.15 mmH2O) 30.5 dB(A) 1.92 W 4500 RPM 2 lead wires
BFB04512VHD-R00
BFB04512VHD-R00, 45x45x20 mm, 12 VDC, 0.16 A, 1.92 Watts, 4500 RPM, 2 lead wires, Locked Rotor Sensor, ball bearing, blower, dc fan, delta BFB04512VHD-R00, 45x45x20 mm, 12 VDC, 0.16 A, 1.92 Watts, 4500 RPM, 2 lead wires, Locked Rotor Sensor, ball bearing, blower, dc fan, delta
Rounded/Rect-45mm L X45mm H 20.00mm Ball 12 VDC 6.01 CFM (0.170 m3/min) 0.557 inchH2O (14.15 mmH2O) 30.5 dB(A) 1.92 W 4500 RPM 3 lead wires
BFB04512VHDX01
BFB04512VHDX01, 45x45x20 mm, 12 VDC, 0.16 A, 1.92 Watts, 4500 RPM, 2 lead wires, Speed Sensor (Tach), ball bearing, blower, dc fan, delta BFB04512VHDX01, 45x45x20 mm, 12 VDC, 0.16 A, 1.92 Watts, 4500 RPM, 2 lead wires, Speed Sensor (Tach), ball bearing, blower, dc fan, delta
Rounded/Rect-45mm L X45mm H 20.00mm Ball 12 VDC 6.01 CFM (0.170 m3/min) 0.557 inchH2O (14.15 mmH2O) 30.5 dB(A) 1.92 W 4500 RPM 3 lead wires
BFB0505HA-C
BFB0505HA-C BFB0505HA-C
Square-50mm L X 50mm H 10.30mm Ball 5 VDC 3.53 CFM (0.100 m3/min) 0.563 inchH2O (14.31 mmH2O) 32.5 dB(A) 0.90 W 5100 RPM 2 lead wires
BFB0505HHA-CY2C
BFB0505HHA-CY2C BFB0505HHA-CY2C
Square-50mm L X 50mm H 10.30mm Ball 5 VDC 3.98 CFM (0.113 m3/min) 0.790 inchH2O (20.09 mmH2O) 37.5 dB(A) 1.30 W 5900 RPM 3 lead wires
BFB0505LA-C
BFB0505LA-C BFB0505LA-C
Square-50mm L X 50mm H 10.30mm Ball 5 VDC 2.19 CFM (0.062 m3/min) 0.208 inchH2O (5.48 mmH2O) 22.5 dB(A) 0.30 W 3500 RPM 2 lead wires
BFB0512H
BFB0512H BFB0512H
Round-51mm Diameter 15.00mm Ball 12 VDC 3.88 CFM (0.110 m3/min) 0.709 inchH2O (18.00 mmH2O) 38.0 dB(A) 1.92 W 5500 RPM 2 lead wires
BFB0512HA-C
BFB0512HA-C, 50x50x10.30mm, 12VDC, ball bearing, blower, 0.12 A, 1.44 Watts, speed 5100 RPM, 2 lead wires, dc fan, delta fan BFB0512HA-C, 50x50x10.30mm, 12VDC, ball bearing, blower, 0.12 A, 1.44 Watts, speed 5100 RPM, 2 lead wires, dc fan, delta fan
Square-50mm L X 50mm H 10.30mm Ball 12 VDC 3.53 CFM (0.100 m3/min) 0.563 inchH2O (14.31 mmH2O) 32.5 dB(A) 1.44 W 5100 RPM 2 lead wires
BFB0512HA-CF00
https://www.delta-fan.com/Download/Images/BFB45x45x10-C.jpg https://www.delta-fan.com/Download/Images/BFB45x45x10-C.jpg
Square-50mm L X 50mm H 10.30mm Ball 12 VDC 3.53 CFM (0.100 m3/min) 0.563 inchH2O (14.31 mmH2O) 32.5 dB(A) 1.44 W 5100 RPM 3 lead wires
BFB0512HA-CX3D
BFB0512HA-CX3D BFB0512HA-CX3D
Square-50mm L X 50mm H 10.30mm Ball 12 VDC 3.53 CFM (0.100 m3/min) 0.563 inchH2O (14.31 mmH2O) 32.5 dB(A) 1.44 W 5100 RPM 4 lead wires
BFB0512HD
BFB0512HD BFB0512HD
Square-50mm L X 50mm H 20.00mm Ball 12 VDC 5.51 CFM (0.156 m3/min) 0.517 inchH2O (13.12 mmH2O) 33.8 dB(A) 1.68 W 4500 RPM 2 lead wires
BFB0512H-F00
BFB0512H-F00 BFB0512H-F00
Round-51mm Diameter 15.00mm Ball 12 VDC 3.88 CFM (0.110 m3/min) 0.709 inchH2O (18.00 mmH2O) 38.0 dB(A) 1.92 W 5500 RPM 3 lead wires
BFB0512HHA-C
BFB0512HHA-C, 50x50x10.30mm, 12VDC, ball bearing, blower, 0.16 A, 1.92 Watts, speed 5900 RPM, 2 lead wires, dc fan, delta fan BFB0512HHA-C, 50x50x10.30mm, 12VDC, ball bearing, blower, 0.16 A, 1.92 Watts, speed 5900 RPM, 2 lead wires, dc fan, delta fan
Square-50mm L X 50mm H 10.30mm Ball 12 VDC 3.99 CFM (0.113 m3/min) 0.790 inchH2O (20.09 mmH2O) 37.5 dB(A) 1.92 W 5900 RPM 2 lead wires
BFB0512HHA-CF00
BFB0512HHA-CF00 BFB0512HHA-CF00
Square-50mm L X 50mm H 10.30mm Ball 12 VDC 3.99 CFM (0.113 m3/min) 0.790 inchH2O (20.09 mmH2O) 37.5 dB(A) 1.92 W 5900 RPM 3 lead wires
BFB0512HHD-F00
BFB0512HHD-F00 BFB0512HHD-F00
Rounded/Rect-50mm L x 50mm H 20.00mm Ball 12 VDC 5.83 CFM (0.165 m3/min) 0.636 inchH2O (16.15 mmH2O) 36.5 dB(A) 1.92 W 4900 RPM 3 lead wires
BFB0512HH-F00
BFB0512HH-F00 BFB0512HH-F00
Rounded/Rect-51mm L x 51mm H 15.00mm Ball 12 VDC 4.59 CFM (0.130 m3/min) 0.866 inchH2O (22.00 mmH2O) 45.0 dB(A) 2.52 W 6500 RPM 3 lead wires
BFB0512LA-C
BFB0512LA-C, 50x50x10.30mm, 12VDC, ball bearing, blower, 0.05 A, 0.60 Watts, speed 3500 RPM, 2 lead wires, dc fan, delta fan BFB0512LA-C, 50x50x10.30mm, 12VDC, ball bearing, blower, 0.05 A, 0.60 Watts, speed 3500 RPM, 2 lead wires, dc fan, delta fan
Square-50mm L X 50mm H 10.30mm Ball 12 VDC 2.19 CFM (0.062 m3/min) 0.208 inchH2O (5.48 mmH2O) 22.5 dB(A) 0.60 W 3500 RPM 2 lead wires
BFB0512LA-CF00
https://www.delta-fan.com/Download/Images/BFB45x45x10-C.jpg https://www.delta-fan.com/Download/Images/BFB45x45x10-C.jpg
Square-50mm L X 50mm H 10.30mm Ball 12 VDC 2.19 CFM (0.062 m3/min) 0.208 inchH2O (5.48 mmH2O) 22.5 dB(A) 0.60 W 3500 RPM 3 lead wires
BFB0512LD
BFB0512LD BFB0512LD
Square-50mm L X 50mm H 20.00mm Ball 12 VDC 4.45 CFM (0.126 m3/min) 0.309 inchH2O (7.85 mmH2O) 28.0 dB(A) 1.44 W 3700 RPM 2 lead wires
BFB0512LD-F00
BFB0512LD-F00 BFB0512LD-F00
Square-50mm L X 50mm H 20.00mm Ball 12 VDC 4.45 CFM (0.126 m3/min) 0.309 inchH2O (7.85 mmH2O) 28.0 dB(A) 1.44 W 3700 RPM 3 lead wires
