Search results for afb
Search results for afb

Search results for: 'afb'

Results:

Remaining

Search Entry:

Fan Type

Voltage Rated

Size / Dimension

Width

Air Flow

Static Pressure

Noise

RPM

Power (Watts)

Bearing Type

Features

Ingress Protection

View as Grid List

Show

per page

Part Number	Size/Dimension	Width	Bearing	Voltage	Air Flow	Static Pressure	Noise	Power	RPM	Termination
AFB0612UH-A	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	46.16 CFM (1.307 m3/min)	0.774 inchH2O (19.66 mmH2O)	52.5 dB(A)	8.28 W	8200 RPM	2 lead wires
AFB0612UH-AF00	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	46.16 CFM (1.307 m3/min)	0.774 inchH2O (19.66 mmH2O)	52.5 dB(A)	8.28 W	8200 RPM	3 lead wires
AFB0612VH-A	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	30.48CFM (0.863 m3/min)	0.345 inchH2O (8.76mmH2O)	42.5 dB(A)	2.76 W	5500 RPM	2 lead wires
AFB0612VH-ABF00	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	30.48CFM (0.863 m3/min)	0.345 inchH2O (8.76mmH2O)	42.5 dB(A)	2.76 W	5500 RPM	3 lead wires
AFB0612VH-AF00	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	30.48CFM (0.863 m3/min)	0.345 inchH2O (8.76mmH2O)	42.5 dB(A)	2.76 W	5500 RPM	3 lead wires
AFB0612VH-AR00	Square-60mm L X 60mm H	25.40mm	Ball	12 VDC	30.48CFM (0.863 m3/min)	0.345 inchH2O (8.76mmH2O)	42.5 dB(A)	2.76 W	5500 RPM	3 lead wires
AFB0612VHC-R00	Square-60mm L X 60mm H	13.00mm	Ball	12 VDC	27.72CFM (0.785 m3/min)	0.252 inchH2O (6.41 mmH2O)	38.0 dB(A)	2.88 W	5400 RPM	3 lead wires
AFB0612VHD	Square-60mm L X 60mm H	20.00mm	Ball	12 VDC	19.78 CFM (0.560 m3/min)	0.275 inchH2O (7.00 mmH2O)	33.0 dB(A)	2.16 W	4800 RPM	2 lead wires
AFB0612VHD-F00 (EOL)	Square-60mm L X 60mm H	20.00mm	Ball	12 VDC	29.06 CFM (0.823 m3/min)	0.278 inchH2O (8.72 mmH2O)	33.0 dB(A)	2.16 W	4800 RPM	3 lead wires
AFB0624EH-A	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	38.35CFM (1.086 m3/min)	0.544 inchH2O (13.81 mmH2O)	46.5 dB(A)	5.76 W	6800 RPM	2 lead wires
AFB0624EH-AB	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	38.35CFM (1.086 m3/min)	0.544 inchH2O (13.81 mmH2O)	46.5 dB(A)	5.76 W	6800 RPM	2 lead wires
AFB0624EH-ABR00	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	38.35CFM (1.086 m3/min)	0.544 inchH2O (13.81 mmH2O)	46.5 dB(A)	5.76 W	6800 RPM	3 lead wires
AFB0624EH-AF00	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	38.35CFM (1.086 m3/min)	0.544 inchH2O (13.81 mmH2O)	46.5 dB(A)	5.76 W	6800 RPM	3 lead wires
AFB0624EH-AR00	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	38.35CFM (1.086 m3/min)	0.544 inchH2O (13.81 mmH2O)	46.5 dB(A)	5.76 W	6800 RPM	3 lead wires
AFB0624EH-SP50	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	38.35CFM (1.086 m3/min)	0.544 inchH2O (13.81 mmH2O)	46.5 dB(A)	5.76 W	6800 RPM	4 lead wires
AFB0624EH-TA50	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	38.35CFM (1.086 m3/min)	0.544 inchH2O (13.81 mmH2O)	46.5 dB(A)	5.76 W	6800 RPM	2 lead wires
AFB0624H-A	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	23.38CFM (0.662 m3/min)	0.211 inchH2O (5.35 mmH2O)	34.0 dB(A)	2.16 W	4250 RPM	2 lead wires
AFB0624H-AR00	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	23.38CFM (0.662 m3/min)	0.211 inchH2O (5.35 mmH2O)	34.0 dB(A)	2.16 W	4250 RPM	3 lead wires
AFB0624HB	Square-60mm L X 60mm H	15.00mm	Ball	24 VDC	15.36 CFM (0.435 m3/min)	0.155 inchH2O (3.93 mmH2O)	32.0 dB(A)	1.92 W	4000 RPM	2 lead wires
AFB0624HC	Square-60mm L X 60mm H	13.00mm	Ball	24 VDC	21.22 CFM (0.601 m3/min)	0.163 inchH2O (4.15 mmH2O)	31.5 dB(A)	1.68 W	4200 RPM	2 lead wires
AFB0624HH-A	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	27.54CFM (0.780 m3/min)	0.297 inchH2O (7.55 mmH2O)	40.0 dB(A)	2.64 W	5000 RPM	2 lead wires
AFB0624HH-AR00	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	27.54CFM (0.780 m3/min)	0.297 inchH2O (7.55 mmH2O)	40.0 dB(A)	2.64 W	5000 RPM	3 lead wires
AFB0624HHB	Square-60mm L X 60mm H	15.00mm	Ball	24 VDC	17.30 CFM (0.490 m3/min)	0.195 inchH2O (4.97 mmH2O)	35.0 dB(A)	2.40 W	4500 RPM	2 lead wires
AFB0624HHC	Square-60mm L X 60mm H	13.00mm	Ball	24 VDC	24.65CFM (0.698 m3/min)	0.204 inchH2O (5.19 mmH2O)	35.0 dB(A)	2.16 W	4800 RPM	2 lead wires
AFB0624L-A	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	16.81CFM (0.476 m3/min)	0.113 inchH2O (2.86 mmH2O)	26.5 dB(A)	1.44 W	3100 RPM	2 lead wires
AFB0624LB	Square-60mm L X 60mm H	15.00mm	Ball	24 VDC	11.55CFM (0.327 m3/min)	0.087 inchH2O (2.21 mmH2O)	24.0 dB(A)	0.96 W	3000 RPM	2 lead wires
AFB0624M-A	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	19.78 CFM (0.560 m3/min)	0.155 inchH2O (3.93 mmH2O)	31.0 dB(A)	1.68 W	3600 RPM	2 lead wires
AFB0624MB	Square-60mm L X 60mm H	15.00mm	Ball	24 VDC	13.45 CFM (0.381 m3/min)	0.119 inchH2O (3.01 mmH2O)	29.0 dB(A)	1.44 W	3500 RPM	2 lead wires
AFB0624SH-A	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	34.15CFM (0.967 m3/min)	0.422 inchH2O (10.73 mmH2O)	44.5 dB(A)	4.08 W	6000 RPM	2 lead wires
AFB0624SH-AF00	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	34.15CFM (0.967 m3/min)	0.422 inchH2O (10.73 mmH2O)	44.5 dB(A)	4.08 W	6000 RPM	3 lead wires
