Search results for afb
Search results for afb

Search results for: 'afb'

Results:

Remaining

Search Entry:

Fan Type

Voltage Rated

Size / Dimension

Width

Air Flow

Static Pressure

Noise

RPM

Power (Watts)

Bearing Type

Features

Ingress Protection

View as Grid List

Show

per page

Part Number	Size/Dimension	Width	Bearing	Voltage	Air Flow	Static Pressure	Noise	Power	RPM	Termination
AFB0624SH-TYTH	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	34.15CFM (0.967 m3/min)	0.422 inchH2O (10.73 mmH2O)	44.5 dB(A)	4.08 W	6000 RPM	3 lead wires
AFB0624VH-A	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	30.48CFM (0.863 m3/min)	0.345 inchH2O (8.76mmH2O)	42.5 dB(A)	3.36 W	5500 RPM	2 lead wires
AFB0624VH-AR00	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	30.48CFM (0.863 m3/min)	0.345 inchH2O (8.76mmH2O)	42.5 dB(A)	3.36 W	5500 RPM	3 lead wires
AFB0624VHC	Square-60mm L X 60mm H	13.00mm	Ball	24 VDC	27.72CFM (0.785 m3/min)	0.252 inchH2O (6.41 mmH2O)	38.0 dB(A)	2.88 W	5400 RPM	2 lead wires
AFB0624VHC-F00	Square-60mm L X 60mm H	13.00mm	Ball	24 VDC	27.72CFM (0.785 m3/min)	0.252 inchH2O (6.41 mmH2O)	38.0 dB(A)	2.88 W	5400 RPM	3 lead wires
AFB0648EH-AF00	Square-60mm L X 60mm H	25.40mm	Ball	48 VDC	38.36CFM (1.086 m3/min)	0.544 inchH2O (13.81 mmH2O)	46.5 dB(A)	6.72 W	6800 RPM	3 lead wires
AFB0648EH-AR00	Square-60mm L X 60mm H	25.40mm	Ball	48 VDC	38.36CFM (1.086 m3/min)	0.544 inchH2O (13.81 mmH2O)	46.5 dB(A)	6.72 W	6800 RPM	3 lead wires
AFB0648EH-TP27	Square-60mm L X 60mm H	25.40mm	Ball	48 VDC	38.35CFM (1.086 m3/min)	0.544 inchH2O (13.81 mmH2O)	46.5 dB(A)	6.72 W	6800 RPM	4 lead wires
AFB0648HH-A	Square-60mm L X 60mm H	25.40mm	Ball	48 VDC	27.54CFM (0.780 m3/min)	0.294 inchH2O (0.747 mmH2O)	40.0 dB(A)	3.84 W	5000 RPM	2 lead wires
AFB0648HH-AF00	Square-60mm L X 60mm H	25.40mm	Ball	48 VDC	27.54CFM (0.780 m3/min)	0.294 inchH2O (0.747 mmH2O)	40.0 dB(A)	3.84 W	5000 RPM	3 lead wires
AFB0648HH-AR00	Square-60mm L X 60mm H	25.40mm	Ball	48 VDC	27.54CFM (0.780 m3/min)	0.294 inchH2O (0.747 mmH2O)	40.0 dB(A)	3.84 W	5000 RPM	3 lead wires
AFB0648SH-A	Square-60mm L X 60mm H	25.40mm	Ball	48 VDC	34.15CFM (0.967 m3/min)	0.422 inchH2O (10.73 mmH2O)	44.5 dB(A)	5.28 W	6000 RPM	2 lead wires
AFB0648SH-AR00	Square-60mm L X 60mm H	25.40mm	Ball	48 VDC	34.15CFM (0.967 m3/min)	0.422 inchH2O (10.73 mmH2O)	44.5 dB(A)	5.28 W	6000 RPM	3 lead wires
AFB0648VH-A	Square-60mm L X 60mm H	25.40mm	Ball	48 VDC	30.48CFM (0.863 m3/min)	0.345 inchH2O (0.876mmH2O)	42.5 dB(A)	4.32 W	5500 RPM	2 lead wires
AFB0648VH-AF00	Square-60mm L X 60mm H	25.40mm	Ball	48 VDC	30.48CFM (0.863 m3/min)	0.345 inchH2O (0.876mmH2O)	42.5 dB(A)	4.32 W	5500 RPM	3 lead wires
AFB0705MC-00F0R	Round-65.8mm Diameter	13.00mm	Ball	5 VDC	22.09 CFM (0.626 m3/min)	0.093 inchH2O (2.36 mmH2O)	28.1 dB(A)	1.10 W	2900 RPM	4 lead wires
AFB0712H-A	Square-70mm L X 70mm H	25.40mm	Ball	12 VDC	36.30CFM (1.028 m3/min)	0.217 inchH2O (05.52 mmH2O)	37.5 dB(A)	2.04 W	3900 RPM	2 lead wires
AFB0712HB	Square-70mm L X 70mm H	15.00mm	Ball	12 VDC	33.20CFM (0.940 m3/min)	0.162 inchH2O (4.12 mmH2O)	34.5 dB(A)	2.16 W	3800 RPM	2 lead wires
AFB0712HB-F00	Square-70mm L X 70mm H	15.00mm	Ball	12 VDC	33.20CFM (0.940 m3/min)	0.162 inchH2O (4.12 mmH2O)	34.5 dB(A)	2.16 W	3800 RPM	3 lead wires
AFB0712HC (EOL)	Square-70mm L X 70mm H	13.00mm	Ball	12 VDC	31.01CFM (0.878 m3/min)	0.148 inchH2O (3.75 mmH2O)	35.0 dB(A)	2.64 W	3800 RPM	2 lead wires
AFB0712HC-F00	Square-70mm L X 70mm H	13.00mm	Ball	12 VDC	31.01CFM (0.878 m3/min)	0.148 inchH2O (3.75 mmH2O)	35.0 dB(A)	2.64 W	3800 RPM	3 lead wires
AFB0712HH-A	Square-70mm L X 70mm H	25.40mm	Ball	12 VDC	44.01CFM (1.246 m3/min)	0.311 inchH2O (7.89 mmH2O)	44.0 dB(A)	3.72 W	4700 RPM	2 lead wires
AFB0712HHB	Square-70mm L X 70mm H	15.00mm	Ball	12 VDC	37.54CFM (1.063 m3/min)	0.210 inchH2O (5.33 mmH2O)	38.5 dB(A)	3.12 W	4300 RPM	2 lead wires
AFB0712HHB-F00	Square-70mm L X 70mm H	15.00mm	Ball	12 VDC	37.54CFM (1.063 m3/min)	0.210 inchH2O (5.33 mmH2O)	38.5 dB(A)	3.12 W	4300 RPM	3 lead wires
AFB0712HHC-F00	Square-70mm L X 70mm H	13.00mm	Ball	12 VDC	35.00CFM (0.991 m3/min)	0.196 inchH2O (4.97 mmH2O)	38.5 dB(A)	3.36 W	4300 RPM	3 lead wires
AFB0712HHC-R00 (EOL)	Square-70mm L X 70mm H	13.00mm	Ball	12 VDC	35.00CFM (0.991 m3/min)	0.196 inchH2O (4.97 mmH2O)	38.5 dB(A)	3.36 W	4300 RPM	3 lead wires
AFB0712L-AF00	Square-70mm L X 70mm H	25.40mm	Ball	12 VDC	21.16CFM (0.599 m3/min)	0.078 inchH2O (1.99 mmH2O)	23.0 dB(A)	0.84 W	2300 RPM	3 lead wires
AFB0712LB	Square-70mm L X 70mm H	15.00mm	Ball	12 VDC	23.38CFM (0.662 m3/min)	0.089 inchH2O (2.27 mmH2O)	26.5 dB(A)	0.96 W	2800 RPM	2 lead wires
AFB0712LB-F00	Square-70mm L X 70mm H	15.00mm	Ball	12 VDC	23.38CFM (0.662 m3/min)	0.089 inchH2O (2.27 mmH2O)	26.5 dB(A)	0.96 W	2800 RPM	3 lead wires
AFB0712LC (EOL)	Square-70mm L X 70mm H	13.00mm	Ball	12 VDC	21.19 CFM (0.600 m3/min)	0.079 inchH2O (2.01 mmH2O)	27.0 dB(A)	1.08 W	2800 RPM	2 lead wires
