Search results for qfr
Search results for qfr

Search results for: 'qfr/'

Results:

Remaining

Search Entry:

Fan Type

Voltage Rated

Size / Dimension

Width

Air Flow

Static Pressure

Noise

RPM

Power (Watts)

Bearing Type

Features

Ingress Protection

View as Grid List

Show

per page

Part Number	Size/Dimension	Width	Bearing	Voltage	Air Flow	Static Pressure	Noise	Power	RPM	Termination
QFR0824SHP6	Square-80mm L X 80mm H	25.00mm	Ball	24 VDC	50.3 CFM (1.423 m3/min)	0.318 inchH2O (8.1 mmH2O)	44.2 dB(A)	3.60 W	4300 RPM	4 wire leads
QFR0824HHP6	Square-80mm L X 80mm H	25.00mm	Ball	24 VDC	38.5 CFM (1.089 m3/min)	0.193 inchH2O (4.92 mmH2O)	36.4 dB(A)	1.92 W	3300 RPM	4 wire leads
QFR0812MJ-00P6	Square-80mm L X 80mm H	25.40mm	Ball	12 VDC	49.10 CFM (1.390 m3/min)	0.283 inchH2O (7.20 mmH2O)	43.5 dB(A)	2.88 W	4500 RPM	4 wire leads
QFR0812LJ-00P6	Square-80mm L X 80mm H	25.40mm	Ball	12 VDC	33.50 CFM (0.948 m3/min)	0.141 inchH2O (3.60 mmH2O)	31.5 dB(A)	1.56 W	3150 RPM	4 wire leads
QFR0812GJ-00P6	Square-80mm L X 80mm H	25.40mm	Ball	12 VDC	78.8 CFM (2.23 m3/min)	6.347inchH2O (161.21mmH2O)	50.0 dB(A)	7.92 W	7000 RPM	4 wire leads
QFR0624GHP6	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	34.78CFM (0.98 m3/min)	0.547 inchH2O (13.89 mmH2O)	47.0 dB(A)	3.84 W	7600 RPM	4 wire leads
QFR0624EHP6	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	27.50CFM (0.778 m3/min)	0.349 inchH2O (8.86 mmH2O)	39.5 dB(A)	2.40 W	6000 RPM	4 wire leads
QFR0824UHP5	Square-80mm L X 80mm H	25.00mm	Ball	24 VDC	65.55 CFM (1.854 m3/min)	0.488 inchH2O (12.40 mm H2O)	50.0 dB(A)	5.52 W	5400 RPM	4 wire leads
QFR0824SHP5	Square-80mm L X 80mm H	25.00mm	Ball	24 VDC	52.38CFM (1.482 m3/min)	0.324 inchH2O (8.23 mm H2O)	44.2 dB(A)	3.60 W	4300 RPM	4 wire leads
QFR0824HHP5	Square-80mm L X 80mm H	25.00mm	Ball	24 VDC	39.60CFM (1.120 m3/min)	0.206 inchH2O (5.23 mmH2O)	36.4 dB(A)	2.40 W	3300 RPM	4 wire leads
QFR0624DHP5	Square-60mm L X 60mm H	25.40mm	Ball	24 VDC	49.50 CFM (1.402 m3/min)	1.043 inchH2O (26.50 mmH2O)	55.0 dB(A)	8.40 W	10600 RPM	4 wire leads
QFR0912MJ-00P0	Square-92mm L X 92mm H	25.40mm	Ball	12 VDC	82.45 CFM (2.334 m3/min)	0.394 inchH2O (10.03 mmH2O)	47.5 dB(A)	5.16 W	4700 RPM	4 wire leads
QFR0812MJ-00P0	Square-80mm L X 80mm H	25.40mm	Ball	12 VDC	49.10 CFM (1.390 m3/min)	0.283 inchH2O (7.20 mmH2O)	43.5 dB(A)	8.40 W	4500 RPM	4 wire leads
QFR0812LJ-00P0	Square-80mm L X 80mm H	25.40mm	Ball	12 VDC	33.50 CFM (0.948 m3/min)	0.141 inchH2O (3.60 mmH2O)	31.5 dB(A)	0.20 W	3150 RPM	4 wire leads
QFR0912LJ-00P0	Square-92mm L X 92mm H	25.40mm	Ball	12 VDC	44.94 CFM (1.272 m3/min)	0.137 inchH2O (3.490 mmH2O)	33.5 dB(A)	1.44 W	2850 RPM	4 wire leads
QFR1224GHEYPR	Square-120mm L X 120mm H	38.00mm	Ball	24 VDC	195.68CFM (5.542 m3/min)	1.028 inchH2O (26.105 mmH2O)	64.5 dB(A)	21.84 W	6000 RPM	4 wire leads
QFR0912VH-SP00	Square-92mm L X 92mm H	25.40mm	Ball	12 VDC	70.24 CFM (1.989 m3/min)	0.551 inchH2O (13.99 mmH2O)	45.0 dB(A)	4.80 W	4200 RPM	4 wire leads
QFR0812UHEYDW	Square-80mm L X 80mm H	38.00mm	Ball	12 VDC	105.21 CFM (2.979 m3/min)	1.335 inchH2O (33.91 mmH2O)	60.0 dB(A)	13.80 W	9000 RPM	4 wire leads
QFR0812UH-CX14	Square-80mm L X 80mm H	25.40mm	Ball	12 VDC	70.24 CFM (1.989 m3/min)	0.551 inchH2O (13.99 mmH2O)	50.5 dB(A)	6.60 W	5600 RPM	4 wire leads
QFR0812SH-F00	Square-80mm L X 80mm H	25.40mm	Ball	12 VDC	54.57CFM (1.545 m3/min)	0.331 inchH2O (8.40 mmH2O)	41.2 dB(A)	3.96 W	4300 RPM	3 wire leads
QFR1224GHE-SP01	Square-120mm L X 120mm H	38.00mm	Ball	24 VDC	210.38CFM (5.957 m3/min)	1.170 inchH2O (29.179 mmH2O)	64.0 dB(A)	22.56 W	6000 RPM	4 wire leads
QFR1248GHE-SP01	Square-120mm L X 120mm H	38.00mm	Ball	48 VDC	210.38CFM (5.957 m3/min)	1.170 inchH2O (29.179 mmH2O)	64.0 dB(A)	24.00 W	6000 RPM	4 wire leads
QFR0812SH-CX13	Square-80mm L X 80mm H	25.40mm	Ball	12 VDC	54.57CFM (1.545 m3/min)	0.331 inchH2O (8.40 mmH2O)	41.2 dB(A)	3.96 W	4300 RPM	4 wire leads
QFR0824UHP6	Square-80mm L X 80mm H	25.00mm	Ball	24 VDC	62.18 CFM (1.759 m3/min)	0.475 inchH2O (12.06 mmH2O)	49.6 dB(A)	5.52 W	5300 RPM	4 wire leads
QFR1212GHE	Square-120mm L X 120mm H	38.00mm	Ball	12 VDC	210.38CFM (5.957 m3/min)	1.170 inchH2O (29.179 mmH2O)	64.0 dB(A)	21.60 W	6000 RPM	2 wire leads
QFR1212GHEXUM	Square-120mm L X 120mm H	38.00mm	Ball	12 VDC	210.38CFM (5.957 m3/min)	1.170 inchH2O (29.179 mmH2O)	64.0 dB(A)	21.60 W	6000 RPM	4 wire leads
QFR0912GJ-00P0	Square-92mm L X 92mm H	25.40mm	Ball	12 VDC	93.67 CFM (2.650 m3/min)	0.513 inchH2O (13.05 mm H2O)	51.0 dB(A)	8.52 W	5600 RPM	4 wire leads
QFR0812GJ-00P0	Square-80mm L X 80mm H	25.40mm	Ball	12 VDC	88.44 CFM (2.720 m3/min)	0.805 inchH2O (20.46 mm H2O)	57.5 dB(A)	11.64 W	8000 RPM	4 wire leads
QFR0824HHP0	Square-80mm L X 80mm H	25.00mm	Ball	24 VDC	39.60CFM (1.120 m3/min)	0.488 inchH2O (12.40 mm H2O)	50.0 dB(A)	5.52 W	3300 RPM	4 wire leads
QFR0824SHP0	Square-80mm L X 80mm H	25.00mm	Ball	24 VDC	52.38CFM (1.482 m3/min)	0.324 inchH2O (8.23 mm H2O)	44.2 dB(A)	3.60 W	4300 RPM	4 wire leads
